Meshtastic Wifi Heltec LoRa 32 V3 With Case 868MHZ ESP32 Oled SX1262 0.96 Inch Blue OLED Display Development Board for Arduino
With Shell / 433MHz
$176.00 USD
Skip to product information
Our Services& Strengths
Meshtastic Wifi Heltec LoRa 32 V3 With Case 868MHZ ESP32 Oled SX1262 0.96 Inch Blue OLED Display Development Board for Arduino
$176.00 USD
Shipping calculated at checkout.
SPECIFICATIONS
Accessory Type: USB To DC Cable
Battery: 3.7V lithium battery power supply and charging
Battery Included: no
Bluetooth: Bluetooth 5 (LE)
Brand Name: Heltec Automation
Certification: CE,FCC
Compatible With: Lora 32
Demo Board Type: RISC-V
Dimensions: 50.2 * 25.5* 10.2 mm
Frequency: 470~510MHz, 863~928MHz
Function: ESP32 LoRa WiFi BLE
High-concerned chemical: none
Intergrated Feature: WiFi 802.11b/g/n,bluetooth
LoRa Node Chip: SX1262
Master Chip: ESP32 S3FN8 (Xtensa 32 bit lx7 dual core processor)
Max. Receiving sensitivity: -136dBm@SF12 BW=125KHz
Max. TX Power: 20±2dBm
Origin: Mainland China
Supported: meshstatic
Typical Application Fields: Internet of Things (IoT)
USB to Serial Chip: CP2102
Wi-Fi: 802.11 b/g/n, up to 150Mbps
Description
Why do we need Maker series products?
Summary
WiFi LoRa 32 (V3) is a classic IoT dev board designed & produced by Heltec Automation. Since its launch in 2017, it has been loved by developers and makers. Widely used in numerous excellent open-source projects and directly made into products for LoRa/LoRaWAN features.
The newly launched V3 version has the same pin sequence as the V2 version and retains Wi-Fi, BLE, LoRa, OLED display, and other functions.
WiFi LoRa 32 (V3) supports the following development methods:
Compared to WiFi LoRa 32 (V2), V3 has made the following upgrades:
WiFi LoRa 32 is compatible with the following open-source projects:
We also provide a standard ESP32 Arduino LoRaWAN library:
This library is already included in the Heltec ESP32 Arduino Framework by default.
Resource
Heltec ESP32 Arduino Framework(Include ESP32 Arduino LoRaWAN library)
More info about Heltec products:
Company Overview
●Chengdu Heltec Automation Technology Co., Ltd. ( English abbreviation Heltec Automation).
●At present, The company's research and development and production include OLED dot matrix screen, electronic ink screen, IoT series products, LoRa supporting solutions and high-precision temperature controllers with automatic control algorithms as the core.
●At present, there is a strong technical research and development team, a scientific production and manufacturing platform and a strict quality management system.
Our Services& Strengths
Stable performance, cost-effective products, high-quality and superior service, our products have not only gained a good reputation in the country, but also received high-quality evaluation in France, Germany, Russia, the United States, South Korea and other countries.
1). Rigorous quality assurance system.
2). High level of service awareness.
3). High quality team.
4). Components use well-known brands.
5). Quick response customer program.
6). Self-owned processing plant, rapid production, equipped with automatic SMT placement machine, automatic screen printing machine and reflow oven.
Details
This product is crafted with quality materials to ensure durability and performance. Designed with your convenience in mind, it seamlessly fits into your everyday life.
Shipping & Returns
We strive to process and ship all orders in a timely manner, working diligently to ensure that your items are on their way to you as soon as possible.
We are committed to ensuring a positive shopping experience for all our customers. If for any reason you wish to return an item, we invite you to reach out to our team for assistance, and we will evaluate every return request with care and consideration.
